Attenuation
|
RG6 60%
|
RG6Tri
|
RG6Quad
|
|
f(MHz)
|
Max dB/100m
|
Max dB/100m
|
Max dB/100m
|
|
5
|
1.87
|
1.87
|
1.87
|
|
50
|
4.80
|
4.80
|
4.80
|
|
200
|
9.70
|
9.70
|
9.70
|
|
300
|
12.20
|
12.20
|
12.20
|
|
400
|
14.09
|
14.09
|
14.09
|
|
450
|
15.20
|
15.20
|
15.20
|
|
500
|
16.02
|
16.02
|
16.02
|
|
550
|
16.80
|
16.80
|
16.80
|
|
600
|
17.55
|
17.55
|
17.55
|
|
750
|
20.67
|
20.67
|
20.67
|
|
860
|
21.00
|
21.00
|
21.00
|
|
1000
|
23.11
|
23.11
|
23.11
|
|
1350
|
26.85
|
26.85
|
26.85
|
|
1750
|
30.57
|
30.57
|
30.57
|
|
2150
|
33.88
|
33.88
|
33.88
|
|
|
DC Resistance of inner conductor(Ω/km)
|
110CCS
|
22 BC
|
|
DC Resistance of outer conductor(Ω/km)
|
37 AL
|
19TC
|
|
Impedance(Ω)
|
75±3.0
|
|
Capacitance(pF/m)
|
54±3.0
|
|
Waveve locity rate%
|
82%
|
|
Returm loss(>dB)
|
VHF 5-300MHz
|
20dB
|
|
UHF 300-960 MHz
|
18dB
|
|
|
|
