Physical Dimensions
|
|
Component
|
Standard Shield
|
Tri-Shield
|
Super-Shield
|
|
Inches
|
mm
|
Inches
|
mm
|
Inches
|
mm
|
|
Nominal Conductor Diameter
|
0.064
|
1.63
|
0.064
|
1.63
|
0.064
|
1.63
|
|
Nominal Diameter Over Dielectric
|
0.280
|
7.11
|
0.280
|
7.11
|
0.280
|
7.11
|
|
Nominal Diameter Over First Shield(Tape)
|
0.287
|
7.29
|
0.287
|
7.29
|
0.287
|
7.29
|
|
Nominal Diameter Over Jacket
|
0.395
|
10.03
|
0.395
|
10.03
|
0.405
|
10.29
|
|
Nominal Jacket Wall Thickness
|
0.042
|
1.07
|
0.039
|
0.99
|
0.037
|
0.94
|
|
Nominal Diameter of Steel Messenger
|
0.051(single)
|
1.83
|
0.051(single)
|
1.83
|
0.051(single)
|
1.83
|
|
0.072(dual)
|
2.77
|
0.072(dual)
|
2.77
|
0.072(dual)
|
2.77
|
